Similar to the M8 type shank page wheel, the M10 type is also divided into several types, such as M10 Straight Hole, M10 with shank and M10 Screw Hole. Similarly, the 10 in M10 means that the middle aperture is 10mm, and the middle of the page turning wheel adopts imported high-quality special glue. For bulk selections of mounted flap wheels, click here.
Grit Size
40#, 60#, 80#, 100#, 120#, 150#, 180#, 240#, 320#, 400#, 600# (dimensions smaller then 15mm starts with 80#)
Raw Material
Coated Abrasive Clothes, Silicon Carbide, Aluminium Oxide, and Ceramic combined, Zirconia, etc, with different brands, e.g. Klingspor, Sait, Deerfos, NCA, 3M, etc)
Reducing wear and thermal load of the workpiece can be achieved by reducing contact pressure and speed (abrasive paste/oil can be used when appropriate)
In order to avoid unnecessary tool wear and thermal load,choose to switch to coarser-grit abrasive clothes instead of increasing contact pressure to increase cutting force
Increasing the cutting speed achieves a slightly finer surface.
Increasing the contact pressure makes the surface slightly more coarse and if you use the same grit size on soft or hard material the surface finish will look coarse on the softer material.
With high elasticity, good synchronous consumption, suitable for a variety of plane,curved surface and corner polishing.
