Grinding Head G

KEYING Mounted Head is made of imported raw materials and special equipment with automatic production and excellent quality. These products are designed to meet the needs of individual grinding tool applications and come in a wide range of particle types, granularity, hardness levels, and shapes. To select the correct installation point, consideration must be given to the material, main application area, and specific operational requirements. We will explain to you the appropriate materials for the different types (mounted point grinding wheel, abrasives and binders) and the task at hand.

Grinding Head G

Raw Material

  • Brown Fused Alumina

  • White Fused Alumina

  • Single Crystal Corundum

  • Chrome Corundum

  • Zircon Corundum

  • Black Corundum

  • Green Silicon Carbide

  • Black Silicon Carbide

  • Microlite Corundum


Grit Size

46#, 60#, 80#, 100#,120#

Colour

Brown, Blue, Orange, White, Black, Pink, Light Blue, Grey Black, Green

Shank Dimension

Shank dia. 3mm=30mm shank length

Shank dia. 3.175mm (1/8"")= 30mm shank lenghth

Shank dia. 6mm=35mm shank length

Shank dia. 6.35mm=35mm shank lengthShank dia.8mm= 40mm shank length

Other shank sizes and length can be customized.

Hardness

Very hard, hard, medium, soft, very soft, extremely soft


Applications

Surface: Edges and difficult reached angels, Deburring, Grinding, Welding removing, Finishing, Prepare for grouting, Roughening

Material Apply: Steel, Cast steel, Stainless steel, Non-ferrous metals, Cast iron, Plastics, rubber, wood

Types Of Grinding Head G


By Shape

By Material

By Size


    Products
    Oil Stone

    Working Principle of Grinding Head G
