Non-woven Abrasive Cloth Flap Disc 4-1/2inch

non woven abrasive cloth flap disc   plate shape ps
Non-woven Abrasive cloth Flap Disc 2
Non-woven Abrasive cloth Flap Disc 1
Non-woven Abrasive cloth Flap Disc 100 16 4
Non-woven Abrasive cloth Flap Disc 100 16 1
Non-woven Abrasive cloth Flap Disc 100 16 c

The non-woven and abrasive-cloth flaps are stuck to a glass-fabric backing pad, meaning that the discs can be used face-down on large surfaces. Long tool life is achieved through the dense packing of the flaps.

The non woven disc is designed for working on large surfaces with speed-adjustable angle grinders.

Table of Non-woven Abrasive Cloth Flap Disc 4-1/2inch



Non-woven Abrasive Cloth Flap Disc 4-1/2inch Non-woven Flap Disc Size Table

Non-woven Abrasive Cloth Flap Disc 4-1/2inch Non-woven Flap Disc Size Table


Non-woven Abrasive Cloth Flap Disc 4-1/2inch Specification:

  • Diameter: 4-1/2 inch=115mm

  • Max. RPM: 13300 RPM

  • Raw Materials: Aluminum Oxide(AO), Silicon Carbide(SC)

  • Grit Size: Coarse-60#/80#, Medium-100#/120#, Fine-150#/180#, Very Fine-240#/320#, Ultra Fine-400#/600#, Micro Fine-800#/1000#

  • Shank Diameter: 3mm, 6mm, 3.175mm, 6.35mm (Other sizes can be customized)


Non-woven Abrasive Cloth Flap Disc 4-1/2inch Materials that can be worked:

  • Aluminum

  • Cobalt-based alloys

  • Other non-ferrous metals

  • High-temperature-resistant materials

  • Nickel-based alloys (e. g. Inconel and Hastelloy)

  • Bronze

  • Hard non-ferrous metal

  • Titanium

  • Titanium alloys

  • Copper

  • Soft non-ferrous metal

  • Brass

  • Zinc

  • Stainless steel (INOX)

  • Thermoplastics

  • Fiber-reinforced duroplastics (GRP, CRP)

  • Hardened, heat-treated steels over 1,200 N/mm2 (over 38 HRC)

  • Steel, cast steel

Non-woven Abrasive Cloth Flap Disc 4-1/2inch Applicable Industries

Applications

  • Roughening

  • Deburring

  • Surface work

  • Cleaning

  • Structuring (matt finishing, brush matting, and satin finishing)

  • Fine grinding in multiple steps

Non-woven Abrasive Cloth Flap Disc 4-1/2inch Applicable Industries

Safety Warning of Non-woven Abrasive Cloth Flap Disc 4-1/2inch

Instructions:

1. Please try to choose an operation indoor environment and wear protective guards and goggles.

2. Never exceed the recommended maximum permitted rotational speed for safety reasons.

3. In order to have a good stock removal rate, quality of surface, and thermal loading on the workpiece, the best performance would be with a recommended cutting speed of 15-20m/s.

4. Don't push and increase the pressure during the processing to achieve a finner surface looking, but try to switch to different grit flap wheels.


Safety Warning:

1. The clamping length between shank and grinders should be more than 15mm.

2. Never exceed the maximum safe speed when the shank is extra long. Try to consult your sales to check the safety rotating speed before use.
