Cartridge Rolls With Shank

This Cartridge Rolls with Shank are made of Import World Quality Raw Materials, they are used on high-speed portable tools, when the outer of the spirally Aluminium Oxide cloth wear away then constantly exposing new abrasive. Sanding cartridge rolls used for weld flash removal, deburring, blending and polishing applications. A steel mandrel must be used to secure the abrasive to the tool.

Grit Size

40#~600#

Raw Material

Aluminium oxide 609; Zirconia

Types Of Tapered Cartridge Rolls with Shank

By Shape

By Material

By Size

Working Principle of Tapered Cartridge Rolls With Shank

When using tapered cartridge rolls, Reducing wear and thermal load of the workpiece can be achieved by reducing contact pressure and speed (abrasive paste/oil can be used when appropriate)
In order to avoid unnecessary tool wear and thermal load, choose to switch to coarser-grit abrasive clothes instead of increasing contact pressure to increase cutting force
Increasing the cutting speed achieves a slightly finer surface.
Increasing the contact pressure makes the surface slightly more coarse and if you use the same grit size on soft or hard material the surface finish will look coarse on the softer material.
