Miniature Unmounted Flap Wheel - Screw Shank

flap sanding wheel head screw shank

KEYING Miniature Unmounted Flap Wheels are characterized by high elasticity, high performance, strong grinding force. This Miniature Unmounted Flap Wheel has Screw Shank. KEYING Manufacturer takes into account that many users in the industrial processing because of the particularity of the use and the workpiece, the ordinary Unmounted Flap Wheel can not meet, all we in order to improve the handle wheel in the processing of the application ability, customized for customers, this product to accept customized range including height, aperture, material, handle length and so on.

Such as:

Some customers want to try the Unmounted Flap Wheel with Screw Shank, because the biggest advantage of the Screw Shank is that it can be screwed to the polishing machine quickly, so we specially make the Unmounted Flap Wheel with Screw Shank to meet the needs of customers.

Specifications of Flap Sanding Wheel Head - Screw Shank

Application

·Stainless Steel

·Metal

·Non-Ferrous Metal

·Aluminum Alloy Products

·Cast Iron, Etc

BrandKEYINGCommodity Code
Compatible Tool

Electric Tool

Pneumatic Tool

Electric Mill

Manipulator And Other Tools

Country Of OriginChinaRaw MaterialAccept Customers' Materials For Processing
Inner Hole Size3mm, 6mm, 3.175mm, 6.35mm, 8mm, 10mm
(Other Shank Dimensions Can Becustomized)
For Use On

·Metal Surface Treatment

·Derusting

·Deburring

·Cleaning Welding Scar

·Cleaning Coating

·Polishing

 ·Painting Removingand Pre-Treatment.

Grit Size60#、80#、100#、120#、
150#, 180#, 240#, 320#, 600#
(Other Grit Size Can Becustomized)
Outside Diameter Range8mm-55mm
(Other Size Can Becustomized)
Industries

·Mechanical   Processing

·Hardware

·Casting

·Auto Parts

·Aviation

·High-Speed Train

·Ship Building

·Other Early And Fine Processing Industries

Cloth BaseDomestic Abrasive Clothes
lmported Abrasive Clothes
Maximum RPM15000-20000Shape

Processing With Supplied Samples

Processing With Supplied Drawings

Shank Length30mm/35mm
(Other Length Can Be Customized)
3mm Diameter: 30-80mm
6mm Diameter: 40-100mm


Features of Flap Sanding Wheel Head - Screw Shank

KEYING Unmounted Flap Wheel is a consumable industrial product in the polishing and grinding head series in the Chinese abrasive and abrasive market, which belongs to a kind of accessories in mechanical processing. This product has a variety of specifications, including diameter, height, particle size, aperture, handle length, material, and other different properties.

  • Made of emery cloth and resin laminated, sand page layers arranged, grinding head grinding cutting sharp.

  • Adopt resin bonding, the blade will not fly when running at high speed, customers can feel at ease to use.

  • Sandpaper blades of different granularity grind out different product surface smoothness. The smaller the particle size, the rougher it is polished, the larger the particle size, the smoother it is polished.

  • This product has a variety of specifications and granularity, accepts non-standard size customization, including height, aperture, material, handle length, etc.

Miniature Unmounted Flap Wheel - Screw Shank Applicable Industries

Applicable Industries

  • Mechanical processing

  • Hardware

  • Casting

  • Auto parts

  • Aviation

  • High-speed train

  • Ship building

  • Other early and fine processing industries


    Matching tool drives

  • Electric tools

  • Pneumatic tools

  • Electric mill

  • Manipulator and other tools

Miniature Unmounted Flap Wheel - Screw Shank Applicable Industries

Product Instructions

Soaked in hot water above 60 degrees for 2-3 minutes before use, so that the emery cloth is fully damp. In the process of grinding, the dust is not only small, the emery cloth will not produce the phenomenon of fragmentation, but also can improve the service life, thereby reducing the loss and reducing the cost. Pay attention to the positive and negative directions when clamping, idling for 1 minute before use.

Miniature Unmounted Flap Wheel - Screw Shank Applicable Industries
If you have any questions, please contact us immediately
Contact Keying Abrasives Now
