Miniature Unmounted Flap Wheel - Standard DIY

miniature unmounted flap wheel   one hole
30 20 6 2
20 16 6 2
12 12 3 4
40 5 6 3

KEYING Miniature Unmounted Flap Wheels are characterized by high elasticity, high performance, strong grinding force. Our Unmounted Flap Wheel is characterized by the ability to fit with different materials and irregular surfaces without dead angles, flexible surface contact, processing application feel is more elastic than the handle page-wheel and effortlessly. Our Standard Unmounted Flap Wheel can meet the needs of most customers.

  • Mainly used in mechanical processing, hardware, casting, auto parts, aviation, high-speed train, shipbuilding and other early and fine processing industries.

  • Especially suitable for Steel, Cast steel, Stainless, steel (INOX), Non-ferrous metals, Cast iron, Plastics and other materials.

  • Unmounted Flap Wheel is a kind of abrasive abrasive wheel in the head can be replaced, and the biggest difference with the handle wheel is that the head can be manually removed, without frequent replacement of the supporting tool chuck rod.

Specifications of Flap Sanding Wheel Head - Standard DIY

Application

·Stainless Steel

·Metal

·Non-Ferrous Metal

·Aluminum Alloy Products

·Cast Iron, Etc

BrandKEYINGCommodity Code
Compatible Tool

Electric Tool

Pneumatic Tool

Electric Mill

Manipulator And Other Tools

Country Of OriginChinaRaw MaterialAluminium Oxide
Silicon Carbide
Zirconia
Inner Hole Size3mm, 6mm, 3.175mm, 6.35mm, 8mm, 10mmFor Use On

·Metal Surface Treatment

·Derusting

·Deburring

·Cleaning Welding Scar

·Cleaning Coating

·Polishing

·Painting Removingand Pre-Treatment.

Grit Size60#, 80#, 100#, 120#, 150#, 180#, 240#, 320#, 600#
Outside Diameter Range8mm-55mmIndustries

·Mechanical Processing

·Hardware

·Casting

·Auto Parts

·Aviation

·High-Speed Train

·Ship Building

·Other Early And Fine Processing Industries

Cloth BaseDomestic Abrasive Clothes
lmported Abrasive Clothes
Maximum RPM15000-20000ShapeStandardStandard Pack Quantity20pcs/40pcs/50pcs/80pcs/100pcs


Features of Flap Sanding Wheel Head - Standard DIY

KEYING Unmounted Flap Wheel is a consumable industrial product in the polishing and grinding head series in the Chinese abrasive and abrasive market, which belongs to a kind of accessories in mechanical processing. This product has a variety of specifications, including diameter, height, particle size, aperture, handle length, material and other different properties.

  • Made of emery cloth and resin laminated, sand page layers arranged, grinding head grinding cutting sharp.

  • Adopt resin bonding, the blade will not fly when running at high speed, customers can feel at ease to use.

  • Sandpaper blades of different granularity grind out different product surface smoothness. The smaller the particle size, the more rough it is polished, the larger the particle size, the smoother it is polished.

Micro-Mini Unmounted Flap Wheel - Standard DIY Applicable Industries

Applicable Industries

  • Mechanical processing

  • Hardware

  • Casting

  • Auto parts

  • Aviation

  • High-speed train

  • Ship building

  • Other early and fine processing industries


  • Matching tool drives

  • Electric tools

  • Pneumatic tools

  • Electric mill

  • Manipulator and other tools

Micro-Mini Unmounted Flap Wheel - Standard DIY Applicable Industries

Product Instructions

Soaked in hot water above 60 degrees for 2-3 minutes before use, so that the emery cloth is fully damp. In the process of grinding, the dust is not only small, the emery cloth will not produce the phenomenon of fragmentation, but also can improve the service life, thereby reducing the loss and reducing the cost. Pay attention to the positive and negative directions when clamping, idling for 1 minute before use.
