Aluminum Oxide Cartridge Rolls With Shank (AO)

aluminum oxide cartridge rolls with shank ao 1
cartridge rolls with shank   conical shape bs 7
cartridge rolls with shank   conical shape bs 4
cartridge rolls with shank   conical shape bs 5
cartridge rolls with shank   cylinder shape cl 2
cartridge rolls with shank   cylinder shape cl 3
cartridge rolls polishing1

Aluminum oxide is a popular choice among industrial professionals because of its fast cut-rate and long life. This mineral makes a tough, durable abrasive that self-fractures to expose fresh cutting edges, whereas traditional natural abrasives dull more quickly. Due to its fast cut rate, hardness, and strength, it is widely used in grinding applications in addition to sanding and finishing applications.

Aluminum Oxide Cartridge Rolls with Shank (AO) Grit Size Table Corresponding To Raw Materials



Aluminum Oxide Cartridge Rolls with Shank (AO) Cartridge Rolls with Shank Size Table

Aluminum Oxide Cartridge Rolls with Shank (AO) Cartridge Rolls with Shank Size Table


Aluminum Oxide Cartridge Rolls with Shank (AO) Specification:

  • Max. RPM:12000~25000 RPM

  • Other Raw Materials: Zirconia(Z)

  • Grit Size (Aluminum Oxide): 40#/60#/80#/100#/120#/150#/180#/240#/320#/400#/600#

  • Other custom tapered cartridge rolls can be customized.


Aluminum Oxide Cartridge Rolls with Shank (AO) Materials that can be worked:

  • Titanium

  • Other non-ferrous metals

  • Hard non-ferrous metal

  • Copper

  • Soft non-ferrous metal

  • Brass

  • Stainless steel (INOX)

  • Grey/nodular cast iron (GG/GJL, GGG/GJS)

  • Annealed cast iron

  • Thermoplastics

  • Fiber-reinforced duroplastics (GRP, CRP)

  • Hardened, heat-treated steels over 1,200 N/mm2 (over 38 HRC)

  • Steel, cast steel


Aluminum Oxide Cartridge Rolls With Shank (AO) Applicable Industries

Applications

  • Leveling

  • Deburring

  • Work on edges

  • Sharpening

  • Weld dressing

  • Fine grinding in multiple steps

Aluminum Oxide Cartridge Rolls With Shank (AO) Applicable Industries

Safety Warning of Aluminum Oxide Cartridge Rolls With Shank (AO)

Instructions:

Safety Warning of Aluminum Oxide Cartridge Rolls With Shank (AO)


Safety Warning:

The clamping length between shank and grinders should be more than 15mm.

Never exceed the maximum safe speed when the shank is extra long. Try to consult your sales to check the safety rotating speed before use.

If you have any questions, please contact us immediately
