Non-woven Flap Wheel Drum 4-3/8inch

Non-woven Flap Wheel Drum 4-3/8inch 1
Non-woven Flap Wheel Drum 4-3/8inch 2
Non-woven Flap Wheel Drum 4-3/8inch 3
Non-woven Flap Wheel Drum 4-3/8inch 4
Non-woven Flap Wheel Drum 4-3/8inch 5
Non-woven Flap Wheel Drum 4-3/8inch 6

They are made of radially arranged flaps of non-woven abrasive material. Long tool life is achieved through the dense packing of the flaps.

Table of Non-woven Flap Wheel Drum 4-3/8inch

Table of Non-woven Flap Wheel Drum 4-3/8inch

Non-woven Flap Wheel Drum 4-3/8inch Specification:

  • Diameter: 4-3/8 inch=110mm

  • Max. RPM: 4000 RPM

  • Raw Materials: Aluminum Oxide(AO), Silicon Carbide(SC)

  • Grit Size: Coarse-60#/80#, Medium-100#/120#, Fine-150#/180#, Very Fine-240#/320#, Ultra Fine-400#/600#, Micro Fine-800#/1000#

  • Shank Diameter: 3mm, 6mm, 3.175mm, 6.35mm (Other sizes can be customized)


Non-woven Flap Wheel Drum 4-3/8inch Materials that can be worked:

  • Aluminium

  • Cobalt-based alloys

  • Other non-ferrous metals

  • High-temperature-resistant materials

  • Nickel-based alloys (e. g. Inconel and Hastelloy)

  • Bronze

  • Hard non-ferrous metal

  • Titanium

  • Titanium alloys

  • Copper

  • Soft non-ferrous metal

  • Brass

  • Zinc

  • Stainless steel (INOX)

  • Thermoplastics

  • Fiber-reinforced duroplastics (GRP, CRP)

  • Hardened, heat-treated steels over 1,200 N/mm2 (over 38 HRC)

  • Steel, cast steel

Non-woven Flap Wheel Drum 4-3/8inch Applicable Industries

Applications

  • Roughening

  • Deburring

  • Surface work

  • Cleaning

  • Structuring (matt finishing, brush matting, and satin finishing)

  • Fine grinding in multiple steps

Non-woven Flap Wheel Drum 4-3/8inch Applicable Industries

Safety Warning of Non-woven Flap Wheel Drum 4-3/8inch

Instructions:

Safety Warning of Non-woven Flap Wheel Drum 4-3/8inch


Safety Warning:

The clamping length between shank and grinders should be more than 15mm.

Never exceed the maximum safe speed when the shank is extra long. Try to consult your sales to check the safety rotating speed before use.

If you have any questions, please contact us immediately
