Table of Cartridge Rolls 9/32inch

Cartridge Rolls 9/32inch Specification:

Diameter: 9/32 inch=7mm
Max. RPM: 25000 RPM
Raw Materials: Aluminum Oxide(AO), Zirconia(Z)
Grit Size: 40#/60#/80#/100#/120#/150#/180#/240#/320#/400#/600#
Shank Diameter: 3mm、6mm (Other sizes can be customized)

Cartridge Rolls 9/32inch Materials that can be worked:

Titanium
Other non-ferrous metals
Hard non-ferrous metal
Copper
Soft non-ferrous metal
Brass
Stainless steel (INOX)
Grey/nodular cast iron (GG/GJL, GGG/GJS)
Annealed cast iron
Thermoplastics
Fiber-reinforced duroplastics (GRP, CRP)
Hardened, heat-treated steels over 1,200 N/mm2 (over 38 HRC)
Steel, cast steel

Cartridge Rolls 9/32inch Applicable Industries

Applications

Leveling
Deburring
Work on edges
Sharpening
Weld dressing
Fine grinding in multiple steps

Cartridge Rolls 9/32inch Applicable Industries

Safety Warning of Cartridge Rolls 9/32inch

Instructions:

1. Please try to choose an operation indoor environment and wear protective guards and goggles.

2. Never exceed the recommended maximum permitted rotational speed for safety reasons.

3. In order to have a good stock removal rate, quality of surface, and thermal loading on the workpiece, the best performance would be with a recommended cutting speed of 15-20m/s.

4. Don't push and increase the pressure during the processing to achieve a finner surface looking, but try to switch to different grit flap wheels.

Safety Warning:

1. The clamping length between shank and grinders should be more than 15mm.

2. Never exceed the maximum safe speed when the shank is extra long. Try to consult your sales to check the safety rotating speed before use.
