Aluminum Oxide Flap Wheel M8 (AO)

aluminum oxide flap wheel m8 ao
flap wheel m8 with shank 80 50 8 2
flap wheel m8 with shank 80 50 8 3
flap wheel m8 screw hole 80 50 8 3 3
flap wheel m8   screw hole

Aluminum oxide is a popular choice among industrial professionals because of its fast cut-rate and long life. This mineral makes a tough, durable abrasive that self-fractures to expose fresh cutting edges, whereas traditional natural abrasives dull more quickly. Due to its fast cut rate, hardness, and strength, it is widely used in grinding applications in addition to sanding and finishing applications.

Aluminum Oxide Flap Wheel M8 (AO) Grit Size Table Corresponding To Raw Materials

Aluminum Oxide Flap Wheel M8 (AO) Grit Size Table Corresponding To Raw Materials


Aluminum Oxide Flap Wheel M8 (AO) Specification:

  • Max. RPM: 6120~76300 RPM

  • Other Raw Materials: Silicon Carbide(SC), Zirconia(ZR), Ceramic Aluminum Oxide Combined (CAO)

  • Grit Size(Aluminum Oxide): 40#/60#/80#/100#/120#/150#/180#/240#/320#/400#/600#


Aluminum Oxide Flap Wheel M8 (AO) Materials that can be worked:

  • Titanium

  • Other non-ferrous metals

  • Hard non-ferrous metal

  • Copper

  • Soft non-ferrous metal

  • Brass

  • Stainless steel (INOX)

  • Grey/nodular cast iron (GG/GJL, GGG/GJS)

  • Annealed cast iron

  • Thermoplastics

  • Fiber-reinforced duroplastics (GRP, CRP)

  • Hardened, heat-treated steels over 1,200 N/mm2 (over 38 HRC)

  • Steel, cast steel


Flap Wheels with Shank

Flap wheels with Shank are suitable for grinding small area, dead angle, inner hole surface, and slit gaps that are difficult to reach. The Features of the abrasive clothes are various with multipurpose application capacity. It is flexible and rich in tensile strength. It could remove the burr and uneven, rough surface with fast grinding force efficiently, meanwhile, can make sure the performance result achieves a slightly finer surface. It is a good product for pre-painting or mirror finishing preparation procedures.


Advantages:

High flexibility to optimum adaptation to contours

Steadily high stock removal through the entire tool life and aggressive coated abrasive resin is freed up constantly

The design of opening spaces and flat bonded make the abrasive tools can process a face-down position, so can touch closely to the edges and corners.


Aluminum Oxide Flap Wheel M8 (AO) Applications:

  • Leveling

  • Deburring

  • Work on edges

  • Sharpening

  • Weld dressing

  • Fine grinding in multiple steps

Aluminum Oxide Flap Wheel M8 (AO) Applicable Industries

Applicable Industries

■ Chemical processing industries

■ Building

■ Steelworks

■ Tool and mould processing

■ Pipeline

■ Shipping Building

■ Automotive industry

■ Aerospace, gas turbine treatment and repair

■ Machine engineering

■ Application Purpose

Aluminum Oxide Flap Wheel M8 (AO) Applicable Industries

Application Purpose

■ Leveling

■ Deburring and Welding grinding

■ Structuring Surfaces

■ Step-by-step fine grinding

Aluminum Oxide Flap Wheel M8 (AO) Applicable Industries

Safety Warning of Aluminum Oxide Flap Wheel M8 (AO)

 Instructions:

Safety Warning of Aluminum Oxide Flap Wheel M8 (AO)


Safety Warning:

The clamping length between shank and grinders should be more than 15mm.

Never exceed the maximum safe speed when the shank is extra long. Try to consult your sales to check the safety rotating speed before use.

If you have any questions, please contact us immediately
Contact Keying Abrasives Now
